Hard Facing ALLOY-309L

Hard Facing ALLOY-309L

Flux core wire for self shielded metal open arc welding
Products Inquiry

Description

1. Features
  • 22Cr-12Ni stainless steel rutile type, acid flux-cored wire.
  • Suitable for welding dissimilar steels (Austenite/Ferrite).
  • Suitable for welding of base materials that are not easy to heat treatment after welding.
  • Good heat and oxidation resistance below 1100℃.
  • Good resistance to sulfide corrosion.

2. Applications
  • Welding of stainless steel for petroleum and chemical equipment.
  • Welding of stainless steel and low-alloy steel, cast steel, non-alloy steel, and heat-resistant steel.
  • Heat-resistant oxidation treatment for waste incinerators and pulverized coal burners.
  • Welding of glass forming equipment, power boiler pipes, rotary kilns and sintering machines.

3. Typical all-weld metal analysis

    Element          C          Cr        Mo          Ni          Mn           Si
    Minimum       --      22.0         --      12         --         --
    Maximum     0.04       24.0     0.5         15     1.5      0.7


4. Typical all-weld Metal Mechanical properties
    Tensile（RM N/mm2)         Yield (RP0.2 N/mm2)          Elongation (%)          Impact (J)
590 460 35 20℃，70


5. Wire diameter and Packing method
     Wire diameter (mm)             1.2, 1.6         2.4, 2.8                       3.2, 4.0
        Packing method       Wire Spool      Drum      Carton or customized
        Net weight (KG)  12.5 / 15    250 5


6. Welding Parameters
Wire diameter (mm)        1.2 2.8
Current polarity    DC positive connection       DC positive connection
Welding Process Open arc welding Open arc welding
Voltage (V) 26-35 26-35
Current (A) 120-200 160-300
Extension length (mm) 15-25 25-35
Shielding gas CO2 shielded  Self shielded
Welding position  Flat welding Flat welding
